Main Features
1. Full hydraulic double wheel drive and vibration.
2. Double vibration frequency and double vibration amplitues.
3. Hydrostatic center articulated steering,patented crab mechanism.
4. Cabin with air conditooner,comfortable and spacious,the flexible steering seat facilicates the operation.
5. The driver's cabin can be turned on one side as a whole, to faciliatate maintenance.
6. For-type frame, good hold-down property.
7. Hydraulic pump and vibrating motors are of the products made by DANFOSS or REXROTH.
MAIN TECHNICAL PARAMETERS:
MODEL | LTC214 | LTC212 | LTC210 | LTC208 | |
Operating mass | kg | 14000 | 12000 | 10000 | 8000 |
Static linear load | N/cm | 333 | 286 | 238 | 231 |
Vibration amplitude | mm | ||||
High amplitude | 0.8 | 0.8 | 0.67 | 0.67 | |
Low amplitude | 0.4 | 0.4 | 0.34 | 0.34 | |
Vibration frequency | Hz | ||||
High amplitude | 40 | 40 | 45 | 45 | |
Low amplitude | 46 | 46 | 50 | 50 | |
Centrifugal force | KN | ||||
High amplitude | 160x2 | 160x2 | 90x2 | 90x2 | |
Low amplitude | 90x2 | 90x2 | 69x2 | 69x2 | |
Travel speed | Km/h | 0-12 | 0-12 | 0-10 | 0-10 |
Turning speed | mm | 7000 | 7000 | 6000 | 6000 |
Grade ability | % | 40 | 40 | 40 | 40 |
Drum width | mm | 2100 | 2100 | 1730 | 1730 |
Wheelbase | mm | 3717 | 3717 | 3217 | 3217 |
Ground Clearance | mm | 324 | 324 | 258 | 258 |
Overall length | 5060 | 5060 | 4558 | 4558 | |
Overall width | 2250 | 2250 | 1840 | 1840 | |
Overall height | 3300 | 3300 | 2674 | 2674 | |
Diesel model | 6BT5.9 | 6BT5.9 | 4BT3.9 | 4BT3.9 | |
Diesel power | KW | 110 | 110 | 75 | 75 |
